DLS CA31 3 CHANNEL Car Amplifier

Php 16,800.00
DLS CA31 is a three channel amplifier with a nominal output of 2 x 65 Watts + 1 x 170 Watts (1 x 280 Watts in 2 ohm). - Built-in high-pass, low-pass and subsonic filters. - Variable phase control on sub channel. - Protection circuits shut down the amplifier
INQUIRY FORM
Description

Dls Amp A4banner



Performance CA31 – 2×65 W + 1×170 W 3-ch amplifier

CA31 is a three channel amplifier with a nominal output of 2 x 65 Watts + 1 x 170 Watts (1 x 280 Watts in 2 ohm).

– Built-in high-pass, low-pass and subsonic filters.
– Variable phase control on sub channel.
– Protection circuits shut down the amplifier in the event of overloads.
– Phase shift control on sub channel
– High level input with auto start.

The perfect amplifier for a standard installation with a front system in stereo and a subwoofer in the back.
– RMS output power @ 13,8 V, 20Hz – 20 kHz

Specifications

Number of channels: 3
Amplifier class: AB
Output power in 4 ohm: 2 x 65 W RMS
Output power in 2 ohm: 2 x 90 W RMS
Mono sub channel 4 ohm: 170 W RMS
Mono sub channel 2 ohm :   280 W
Damping factor :   >100
S/N ratio, A-weighted: >100 dB
Frequency range : 10 Hz – 35 kHz
Input sensitivity:  0,25 – 5 V
Input impedance : >10 kohm
Input impedance, high level: 100 ohm
Filters channel A & B :   HP: 50-150 Hz
Filter sub channel    Lowpass: 50 – 120 Hz + subsonic 25 Hz
Low level output :  No
Phase control for subwoofers :   0-180 degrees cont. variable
High level input with auto start : Yes
Power consumption (idle) :   1A
Power consumption (max) :   60A
Rec. power cable: Minimum 4AWG / 21 mm2
Fuses : 2 x 30 A
Dimension (W x D x H) : 70 x 357 x 268 mm (2,92 x 14,06 x 10,55 inch)
Weight :  4 kg ( 8,8 lb)

NOTE: Pictures are for visualization only and may vary on actual items.
