DLS Ultimate A5 - The Big Three 3-channel amplifier ULTIMATE series A5, a three-channel amplifier with 2 x 85 Watt stereo rated a 1 x 300 Watts in mono . In two ohm load it delivers 2 x 100 Watts in stereo and 1 x 500 Watts in mono. The mono channel is 1 ohm stable.
DLS Ultimate A5 – The Big Three 3-channel amplifier ULTIMATE series A5, a three-channel amplifier with 2 x 85 Watt stereo rated a 1 x 300 Watts in mono . In two ohm load it delivers 2 x 100 Watts in stereo and 1 x 500 Watts in mono. The mono channel is 1 ohm stable.
Built-in fan control.
Built-in, variable 50-125 Hz switchable high-pass filter and a 40 to 90 Hz low-pass filter for subwoofer.
The Sub-channel is also equipped with a switchable 25 Hz subsonic filter.
The perfect amp for a good front system and one or more subwoofers in the trunk. remote control
-sub-level that includes phase shift control 0-180 degrees.
RMS output power per channel at 13.8 volts, 20 Hz – 20 kHz, <0.1% distortion
Number of Channels 3
class AB amplifier
damping factor> 200
Mono bridge mode 4 ohm N / A
S / N ratio, A -weighted> 100 dB
output into 4 Ohm 2 x 85 W
output into 2 ohms 2 x 100 W
Mono sub channel 4 ohm 300 W
Mono sub channel 2 ohm 500 W
input impedance, high N / A
mono sub channel output in 1 ohm 780 W
frequency range 10 Hz – 50 kHz
input sensitivity 0,2 – 7 V input impedance> 10 kOhm
Filter channel A & B HP: 50-150 Hz
sub channel filter LP: 40-90 Hz, 25 Hz Subsonic / 18 dB
Low-Level Output No
remote bass level control Yes
High-level input with auto start no.
Remote Control Yes Phase shift
External fan Terminal Yes
Phase Control for Subwoofer 0-180 degrees
power consumption (standby) 0.5 A
Power consumption (max) 90 A
Rec Power cable Minimum 4AWG / 21 mm2
fuses 3 x 30 A
Dimensions (W x D x H) 410 x 240 x 73 mm (16.15 x 9.45 x 2.87 inches)
Weight 5.9 kg (13 lb)
